Overview
The CX10 is a compact, high-output coaxial loudspeaker engineered for demanding hospitality installations, distributed audio systems, and small indoor or outdoor events. Building on the same coaxial architecture as the CX6, it delivers smooth, controlled frequency response with consistent coverage both on and off-axis — while offering significantly greater output capability and extended low-frequency performance.
Its 10″ transducer features a weatherproof coating applied to both sides of the diaphragm for increased durability in challenging environments, while a robust 2mm zinc-coated steel grille provides further protection against impact and debris ingress. With a usable bandwidth of 65Hz–18kHz using the Full Range DSP preset, the CX10 performs confidently as a standalone loudspeaker. When paired with a subwoofer such as the Harrier SW15, system response extends down to 32Hz.
Angled side panels at 30° and 45° allow the cabinet to function as a stage monitor, while the rear cut-away enables a low-profile wedge position. M10 rigging points are fitted on all sides, and an integrated 35mm pole mount allows seamless deployment alongside the subwoofer range.
Specifications
| S P E C I F I C A T I O N S | |
| Type | Compact and flexible coaxial loudspeaker |
| Frequency Response 1 | 65Hz – 18kHz (−3dB) |
| HF Driver | 1.75″ VC compression driver |
| LF Driver | 10″ weatherproofed transducer |
| Power Handling HF 2 | N/A |
| Power Handling 2 | 500W Program |
| Recommended Amplifier | Traction Engine 4|1000-DSP |
| Sensitivity 2 | 95dB |
| Maximum SPL 4 | 128dB Peak |
| Nominal Impedance | 8 Ohms |
| Crossover | Internal passive network |
| Connectors | 2× Neutrik® NL4 SpeakOn™ with pins linked (input on 1+/−) |
| Nominal Dispersion (−6dB) | 70° conical |
| Primary Construction | 12mm Birch Plywood |
| Available Finish | Textured black PU coating |
| Dimensions (H × W × D) | 420mm × 294mm × 252mm |
| Fittings | 6× M10 fixing points | 4× M6 fixing points | 35mm pole adapter |
| Weight | 12.15kg |
| Available Accessories | CX10 U-bracket | CX10 Carry Bag |
1 Measured on axis in half (2π) space at two metres and referred to 1 metre. With DSP preset applied.
2 Tested to AES 2-1984 Rev. 2003.
3 Measured in half (2π) space at 2 metres with 2.83V input, using band-limited pink noise, then referred to 1 metre.
4 Calculated at 1 metre.
